Welcome to HS Electronics



We provide Electronics Modules, Cards, PCB, Power Supply, etc for Industrial Machines / Systems





Key Services Offered :

  • Single Board Computer
  • ETX Modules
  • Arcnet Card
  • Touch Screen
  • AC/DC Power Supply
  • ATX / AT SMPS
  • Rackmount Chassis
  • LCD Monitors
  • VME CPU Card
  • CPCI CPU Card
  • Serial / PS2 /Touchpad Mouse
  • IO Cards
  • PLC
  • CNC Monitors
  • 32MB to 8 GB Hard Disk (DoM, DoC, IDE & CF)
  • Software backup and re-storations

15

Team Members



299

Projects Done



100

Awards Won



499

Happy Clients



2000

Established



Power & Energy

Gas Tubines Controls DCS, SCADA .

Marines

Weapons Control System, Navigational Control System, Fin Stabalizers, IPMS, PMS, Engine Control System.

CNC & HMC/VMC Machine

Displays, CPU Card, Touch Screen, I/O Card, Power supply, Drives, Encoders, Sensors, etc

Embroidery Machine

LASSER, Saurer Machine Parts – EPC-4, EPC-8, PMAC, EXM-MX, Hard Disk, Monitor, Touch Screen, Proface GP270 HMI, Power supply.

Ophthalmic Equipment

SatshLOH, V50, V75, V95 , Coating Machine, CPU Card, LCD Display, ELMO SBA, Axis Card, etc

Oil & Gas

Drilling Rig Controls, Camera Monitoring System, DCS, SCADA, Dolch Monitor, Azonix Monitor, Power Drive.

Our Core Services

Single Board Computer

VME, CPCI, PCIMG, ISA, PCI, PISA, Half Size, Full Size, ETX 386SX to P-IV Single Board Computer .

Display & Monitors

HMI, Panel PC, Touch Screen, LCD, TFT, Character, Graphics Display.

Embedded Systems

MS DOS, Windows CE, Windows XP, QNIX, UNIX, LINEX, IDOS, VDOS. Software backup and re-store

Power Supply

AT SMPS, ATX SMPS, 1U & 2U SMPS, AC/DC, DC/DC, Converter, Rectifiers, Inverters.

Drives & VFD

AC Drives, DC Drives, VFD, Servo Drives, Encoder, Techo, Sensors

Controls & Sensor

Encoder, Proximity, Megnatic Loop, Techo, Limit Switches, Panel Indicators, Temp. Controller .

IMG-20150722-WA0004

Question & Answer

Why PCB Fails ?

Functional failure of components, Improper operation, variation of power, environmental conditions, component ageing, and damage to PCB tracks are some of the common reasons of PCB failure. Survey indicates that normally most of the new systems breakdown within the first ten years.

What are normal faults encountered in a PCB repair environment?

Functional IC failures, loaded power supply, input/output pins shorted to VCC or ground, multiplier shorts, faulty de coupling capacitors, Bus faults, Fan out faults, Open/Short of passive devices, Track shorts/opens are some of the most common problems encountered in a PCB. The trouble with doing something right the first time is that nobody appreciates how difficult it was. — from “Fortunes” .

Conventional methods and its limitations?.

Service engineer uses various methods and tools of testing which include conventional equipment’s like Oscilloscopes, Multi meter and logic analyzers. General testing Out-circuit testing is performed which may either require the PCB to be connected to the original circuit / equipment so as to get the necessary input signals. This way the whole / entire equipment is required for the testing and may become cumbersome. Another conventional method needs to remove the PCB and test the components separately. This may cause some major damage as removing and re-soldering has to be done and even the PCB tracks as well as components may get damaged..

How we at HS Electronics are different?

In order to avoid all the above-mentioned problems we in our labs try using new methods. Our methods are the in-circuit testing ones, which do not require removing any components from the PCB. Moreover we at our labs use an intelligent in-circuit tester that tests the PCB at component level. It stimulates appropriate inputs to a device, measures its output response and declares whether it is functionally good or bad. Even complex natured LSI and MSI IC’s are tested and the process is less time consuming with good results. Here we can repair the PCB’s even with out circuit diagram.

Latest News about our Industry

Warehouse

Dhumal Nagar, Waliv, Vasai East.

Refinery

ONGC HPCL, BPCL GAIL NFL IOCL Reliance Essar

Oil Pipeline

Jindal Pipes Essar Oil Fields,.

Iron Smelter

Graphite India Ltd.

Gas Company

GAIL Mahanagar Gas Gujarat Gas ONGC HPCL BPCL IOCL Relaince.

Chemical Plants

NFL RCF Gail
